Locking systems
CLOSING THINGS
IN VARIATION
SECURITY LOCKS FOR WALK-IN STATIONS
An effective security door also includes a locking system that meets the high requirements.
It signals at first glance whether the door is properly locked and ensures that the door can basically only be opened with the key once it has fallen into the lock. In addition, there is a panic function which ensures that no one can lock themselves in by mistake. If desired, the lock can be equipped with two independent door cylinders. For double-walled doors, mortise locks are available in three versions with different functionality.
Příslušenství k dveřím GRITEC
GRITEC mortise lock
- Panic function according to DIN VDE 0101
- Round latch and round bolt
- Baqui rod connection up and down
- optionally one or two profile cylinders
- available with KABA perforation on request
- Key can only be removed with pre-locked latch
- Lock can be used right/left by repositioning the latch
GRITEC substation lock
- Round bar
- Baqui rod connection up and down
- optionally one or two profile cylinders
- available with KABA perforation on request
- Key can only be removed when locked
- Lock can be used right/left
- Rod stroke 15 mm
GRITEC box lock
- Panic function according to DIN VDE 0101
- Round latch
- Baqui rod connection up and down
- optionally one or two profile cylinders
- available with KABA perforation on request
- Key can only be removed when latch is pre-locked
- Lock variants right and left
- Rod stroke 15 mm
GRITEC swivel lock
- to be locked with half cylinder of 40 mm or 45 mm length, length to be specified
- Connection for round rods ø 10 mm upwards and downwards
- Rod stroke 31.4 mm
